Galfan Wire Coating Garden Galvanized Gabion Mesh River Diversion Structures 6×2×0.3m

  • 1
  • 2

Brand Name : ORIENTLAND

Model Number : ORGWB025

Certification : ISO

Place of Origin : ANPING

MOQ : 2000 sqm

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5000 sqm per day

Delivery Time : 7-10days

Packaging Details : Pallet or nude packing

Type : Gabion Wall Basket

Material : Hot dipped galvanized wire, Galfan wire, PVC coated wire

Hole shape : Hexagonal

Wire gauge : 2.0/2.7/3.0/4.0mm

Aperture : 80×100mm, 100×120mm, 120×140mm

Application : Flood control retaining wall, river bank vation, slope protection

Box size : 2m×1m×1m, 1m×1m×1m, 2m×1m×0.5m

Sample : Available and free

Contact Now

Galfan Wire Coating Gabion River Diversion Structures Gabion River es 6×2×0.3m

Products Description:

We now offer Gabions and River es using a new Galfan wire coating, which is a new improved form of Galvanisation, including 95% Zinc coating alloy with 5% Aluminium, it has vastly improved corrosion protection properties; providing 2-3 times more corrosion protection than normal Galvanising !

Internationally, gabion materials have been commonly used since the early 1880’s all over the world and have become one of the most popular soil erosion control and retaining wall solutions. Some have tried to use more rigid, welded-mesh elements and sometimes even plastic materials for gabion materials. However time and again the high strength and flexibility of the honeycomb shaped (hexagonal) steel wire mesh has proven to provide the ultimate solution.

Gabions are supplied in a wide range of sizes, commonly measured firstly in length x width x height of basket (all measurements in metres). Standard sized baskets are available, listed on our website, other sizes can sometimes be made available depending on the quantity required .

Gabion Technical Parameter:

Wire dia.(mm) 2.0 2.2 2.4 2.7 3.0 3.4 3.9
Tolerance(mm) 0.05 0.06 0.06 0.06 0.07 0.07 0.07
Min. Zinc coating(g/m2) 215 230 230 245 255 265 275

Gabion specifications:

Mesh Size Tolerance Diameter Length Width Height Diaphragms

80×100mm

100×120mm

 +16%/-4% 2.0-3.0mm 1.5 1 0.5 0
1.5 1 1 0
2 1 0.5 0/1
2 1 1 0/1
3 1 0.5 0/2
3 1 1 0/2
4 1 1 0/3

River Standard Sizes
Length(m) x Width(m) x Height(m) = Volume (m³) or Length x Width = Plan Area (m2)

2x1x0.3 (0.6m³)
6x2x0.17 (2.04m³)
3x1x0.3 (0.9m³) 6x2x0.23 (2.76m³)
4x1x0.3 (1.2m³) 6x2x0.30 (3.60m³)

Galfan Wire Coating Garden Galvanized Gabion Mesh River Diversion Structures 6×2×0.3m

Gabion box application:

  • Retaining wall structures
  • River and canal training works
  • Erosion and scour protection; roadway protection; bridge protection
  • Hydraulic structures, dams and culverts
  • Coastal defence and protection works
  • Wall Cladding
  • Rockfall and soil erosion protection

Galfan Wire Coating Garden Galvanized Gabion Mesh River Diversion Structures 6×2×0.3m
