3 Inch × 0.5 Inch 8 Gauge Welded steel chain link fence Prison Mesh Fencing

Anping JQ Wire Mesh Products Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

3 Inch × 0.5 Inch 8 Gauge Welded steel chain link fence Prison Mesh Fencing

  • 1
  • 2

Brand Name : ORIENTLAND

Model Number : ORHSF005

Certification : ISO

Place of Origin : ANPING

MOQ : 100units

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100units per week

Delivery Time : 10-15days

Packaging Details : Iron Pallet, Wooden Pallet

Type : Fencing, Trellis & Gates

Surface Treatment : PVC powder coated, Hot dipped galvanized

PVC coated color : Black, green, yellow, blue

Wire diameter : 8 gauge

Hole size : 3"×0.5"

Height : 900-2500mm

Width : 4ft, 8ft, 2.5m, 3m

Post : Peach post, Square post

Application : Fence mesh, prison mesh fence, residential fence

Contact Now

Anti-climb Fence Anti-cut Fence 358 High Security Fence Prison Mesh 3 inch×0.5 inch 8 Gauge


Products Description:

High Security Fence, also called 358 fence, prison mesh, which is well-known as anti-climb and anti-cut fence. Perfectly suited to high security applications,like military, airport, prison, warehouse, factory etc.
This high performance system provides the ultimate protection against anti-climb and cut through. With the additional V-top like barbed wire andrazor barbed wire, the system will have multiple additional features to aid security.

3 Inch × 0.5 Inch 8 Gauge Welded steel chain link fence Prison Mesh Fencing

'358' comes from its measurements 3" x 0.5" x 8 gauge which equates to approx. 76.2mm x 12.7mm x 4mm in metric.

3 Inch × 0.5 Inch 8 Gauge Welded steel chain link fence Prison Mesh Fencing

358 security fences are extremely difficult to penetrate, with the small mesh aperture being effectively finger proof, and extremely difficult to attack using conventional hand tools. 358 fences are recognized as one of the most difficult to break through the barrier because it is difficult to climb. It is called security fencing and high- strength fencing.

358 security fencing panel can be bent in part to enhance the aesthetic effect.

3 Inch × 0.5 Inch 8 Gauge Welded steel chain link fence Prison Mesh Fencing

358 security fence panel description
Mesh Size 3"×0.5" (76.2mm×12.7mm)
Wire Diameter 8 gauge(4mm) Horizontal wire andVertical wire
Welded Strength 540-690N/m2
Surface Treatment

Hot dipped galvanized after welded,

Hot dipped galvanized wire welded+PVC powder coating(Min. 100 micron),

Hot dipped galvanized wire welded+PVC powder painting

358 security fence post description
Material
Post section 60×60mm, 60×80mm, 80×80mm, 120×60mm
Post wall thickness 2.5mm-3.0mm
Treatment Inside/Outside hot dipped galvanized(min 275g/m2), PVC coated
PVC coated Colors Green, black or made by RAL color
Post cap 60×80mm,120×60mm metal caps, 80×80mm plastic caps
Metal clips and clamps are hot dipped galvanized, also can be supplied with PVC coated

Application:

  • Bridge anti-climb guarding&guard safety screening;
  • Sub-station security fencing;
  • Psychiatric hospital security fencing;
  • Factory machine guards;
  • Walkway security fencing;
  • Airport security fencing;
  • 358 wire mesh fence gates;
  • Shipping port security fencing;
  • Electrical sub-station fencing;
  • Water treatment works;
  • Gas security window girlles;
  • Balustrades security fence as well as some other commercal/industrial security fence uses
